Output extension units for ProCon GSM and 4G

21/07/2020 12:00:00 AM

In our previous newsletter, we informed you about our ProCon 4G product that is capable of communicating on the 4G, 3G, and 2G networks. If the signal strength is not sufficient, or you need a future proof solution, the ProCon 4G will be the ideal choice.

The extension modules of the ProCon GSM and the ProLine GSM can be used for the ProCon 4G as well. Hence, if you needed more than one output we would recommend the following extension units:

ExpRelay

  • Expansion panel with one relay output for ProCon GSM and ProLine GSM.
  • The output can be controlled by SMS or by free call
  • The output can be Monostable (up to 65000 seconds) or bistable
  • If the ProCon GSM is used as an alarm center, the output can control the siren
  • In the programming software you can find the expansion module with the name “Kimenet2”

Website>>



ExpRelay3

  • Expansion panel for ProCon GSM and Proline GSM with three relays, which can be loaded max. 50 VDC/1A.
  • 3 pieces of NO/NC relays ( it can be loaded max. 24VDC@1A)
  • The NO/NC operation can be chosen on the expansion module by a jamper
  • The outputs can be controlled by SMS, voice call, via Bluetooth, or even trough GPRS application
  • The outputs can be configured separately (Monostable, bistable)
  • The relays can be managed separately

Website>>



ExpBus + Exp IO8 panel

ExpBus

  • Bus expansion module for ProCon GSM module to connect the EXPIO8 expansion unit.
  • It allows us to connect even 16 EXP8IO units to the ProCon GSM module.

Website>>



Exp IO8 panel​

  • Expansion panel with 8 relay outputs and 8 digital inputs for ProCon GSM module.
  • The outputs can be controlled by SMS
  • The outputs can be Monostable (up to 65000 seconds) or bistable
  • The outputs can be configured by the ProCon GSM module programming software
  • Even 16 expansion modules can be connected to the GSM module simultaneously
  • For using the module ExpBus expansion module is necessary

Website>>
